Noctua NH-U14S CPU Cooler

Noctua NH-U14S CPU Cooler

CL SKU 19146
$ 129 .95

Or 6 Weekly payments from NZD $21.66 what's this?

product in stock 2 in stock
Order now and it ships today!

Award-Winning NH-U Series

The NH-U14S is the first 140mm model in Noctua's award-winning NH-U series. First introduced in 2005, the NH-U series has become a standard choice for premium quality quiet CPU coolers and won more than 400 awards and recommendations from leading international hardware websites and magazines.


Full RAM compatibility on LGA20xx

With its 52mm slim design tailor-made for LGA20xx (LGA2066 & LGA2011), the NH-U14S will not overhang the RAM slots on this platform, thus guaranteeing full compatibility with tall memory modules. On some LGA115x and AMD motherboards, the front fan may overhang the first RAM slot, so standard height RAM (up to 32mm) should be chosen when using the first slot.*


Reasonable size for better overall compatibility

Standing 165mm tall, the NH-U14S is short enough to fit most modern high-end cases. Measuring 150mm wide (including fan and fan clips), the NH-U14S provides better compatibility with SLI and CrossFire setups as compared to tower coolers that are wider than 150mm or use fans wider than 150mm.


NF-A15 140mm PWM Fan

The NF-A15 is a premium quality quiet 140mm fan with a round frame that complies with Noctua's AAO standard. Featuring sophisticated aerodynamic design measures such as Flow Acceleration Channels, the NF-A15 further improves the renowned quiet cooling performance of the award-winning NF-P14.

PWM support and Low-Noise Adaptor

The NF-A15 140mm fan supplied with the NH-U14S supports PWM for convenient automatic speed control through the mainboard. In addition, the maximum fan speed can be reduced from 1500 to 1200rpm using the supplied Low-Noise Adaptor for even quieter operation.


Anti-vibration pads and fan-clips for second NF-A15 (optional)

For users who want to achieve even better performance by adding a second, optional NF-A15 fan to create a push/pull setup, the NH-U14S includes fan clips and an extra set of custom-designed anti-vibration pads that allow to off-set the rear fan by 5mm to improve acoustics in dual-fan mode.*


SecuFirm2™ mounting system

Noctua's SecuFirm2™ mounting systems have become synonymous with quality, safety and ease of use. Supporting Intel LGA115x (LGA1150, LGA1151, LGA1155, LGA1156), LGA2011, LGA2066 and AMD (AM3+, AM2+, FM1, FM2, FM2+), the SecuFirm2™ mounting included with the NH-U14S guarantees perfect contact pressure and maximum convenience on all current sockets.


Compatibility with past and future sockets

Complying with the open SecuFirm™ standard, the NH-U14S can be made compatible with the older LGA1366 and LGA775 sockets using the optional NM-I3 mounting kit, which is provided by Noctua free of charge. If technically possible, Noctua will also provide upgrade kits for future sockets.

NT-H1 thermal compound

Having received more than 100 awards and recommendations from hardware journalists around the world, Noctua's NT-H1 is a proven professional grade TIM solution that provides minimum thermal resistance, excellent ease of use and outstanding reliability.


6-year manufacturer’s warranty

Noctua products are renowned for their impeccable quality and outstanding longevity. Like all Noctua fans, the supplied NF-A15 features an MTTF rating of more than 150.000 hours and the entire NH-U14S package comes with a full 6-year manufacturer's warranty.


*In cases with more than 165mm CPU cooler clearance, the fan can be moved upwards to make room for memory modules taller than 32mm. If the rear fan is off-set, it may overhang the first left hand side RAM slot on LGA20xx.

Generic

UPC

842431014313

Category

Cooling - CPU

Brand

Noctua

Part Number

NH-U14S

Warranty

6-Year Warranty

Heatsink

Socket Compatibility

AM3

;

AM3/AM2+

;

AM3+

;

LGA1150

;

LGA1151

;

LGA1155

;

LGA1156

;

LGA2011-3

;

LGA2066

;

LGA1151v2

;

AM4

Heatsink Weight

770 g

Form Factor

Tower

Cold Plate Material

Nickel-Plated Copper

Maximum TDP

180 W

Height (with fan)

165 mm

Included Thermal Paste

Noctua NT-H1

Fans

Size

140mm

Fans

1

Maximum RPM

1500 RPM

Minimum RPM

300 RPM

Airflow

140.2 m3/h

Acoustical Noise

24.6 dB

Connector

4-Pin PWM
